Leagacy Products

T4 RAID

macOS Drivers (For Intel-based Macs only; not Apple M1-based Macs):

Interface

2x Thunderbolt 3 Ports
1x DisplayPort port



Power Supply Adapter

AC Input : 100-240V ~2.0A, 50-60Hz
DC Output: 19.5V, 11.8A (230W)



Dimension and Weight

Height: 5.8 inches (148 mm)
Width: 5.3 inches (135 mm)
Depth: 9.5 inches (242 mm)
Weight: 13lb (5.90kg)(HDDx4)



System Requirements
Mac OS X 10.12 or later



Environment

Operating Temperature:5°C ~ 55°C (41°F ~ 131°F)
Storage Temperature:-40°C ~ 70°C (-40°F ~ 158°F)



In the Box

1 x CalDigit T4
4 x Drive Modules
2 x Drive Module Keys
1 x AC Adapter (PSU)
1 x AC Power Cord
1 x Thunderbolt 3 Cable (1.0m, 3.28 ft)
CalDigit Drive Utility software (Preloaded)



Tuff

macOS Icons:
Icons Package



Product Images:
Media Kit

Interface

1 x USB 3.1 Type-C Port - 10Gb/s



Power Supply Adapter

USB Bus-Powered



Dimension and Weight

Height: 5.31 inches (135.0 mm)

Width: 3.52 inches (89.5 mm)

Depth: 0.83 inches (21.0 mm)

Weight: 0.60 lbs (0.27 kg)



System Requirements

Windows 7 or later
Mac OS X 10.8.4 or later

Environment

Ambient Operating
Temperature: 32°F ~ 158°F(0°C ~ 70°C)

In the Box

1 x Tuff
1 x USB-C Cable
1 x USB-C to A Cable

USB-C Dock

macOS Drivers:

Windows Drivers:

Linux Drivers:

Interface

3 x USB 3.1 Gen 1 Type-A Port
1 x USB 3.1 Gen 1 Type-C Port
1 x USB 3.1 Gen 1 Type-C Port (Computer Link)
1 x DisplayPort 1.2
1 x HDMI 2.0
1 x Gigabit Ethernet*
1 x Audio In & Out

Power Supply Adapter

AC Input: 100V-240V~50Hz/60Hz
DC Output: 20V/4.5A, 90W

Dimensions and Weight

Height: 1.10 inches (2.8 cm)
Width: 7.89 inches (20 cm)
Depth: 3.68 inches (9.3 cm)
Weight: 1.32 lbs (0.6 kgs)

System Requirements

USB-C computers
Legacy USB 3.0 computers2
Thunderbolt™ 3 computers1
Mac OS X 10.8.5 or later
Windows 7 or Later
Chrome OS

Environment

Ambient Temp: 0°C~70°C

In the Box

1 x CalDigit USB-C Dock
1 x Power Adapter
1 x USB-C to USB-C Cable

TS3

macOS Drivers:

Capacity: up to 10TB



Size and Weight:

  • Height: 3.6 inches   (92 mm)
  • Width: 5.3 inches   (134 mm)
  • Depth: 8.5 inches   (216 mm)
  • Weight: 6.6lbs          (3.0 kgs)



Host Interface:

  • eSATA x 1
  • FireWire 800 x 2
  • FireWire 400 x 1
  • USB 3.0 x 1



Interface Transfer Rate:

  • eSATA: up to 3Gbits/s
  • FireWire 800: up to 800Mbits/s
  • FireWire 400: up to 400Mbits/s
  • USB 3.0: up to 5Gbits/s



RAID Function:

  • Supports RAID 0, 1, Spanning, JBOD
  • Automatically online fast disk rebuilding
  • Automatic disk failure detection
  • Hot swappable disks
  • USB 3.0 do not support JBOD



Power Supply Adapter:

  • Full range AC Input: 100 ~ 240V 50~60Hz 1.5A
  • DC Output: 5V/4.2A, 12V/3A
  • Power plug: 4Pin



Fan Module:

  • Size: 50(L) x 50(W) x 10(H) mm
  • Rated Voltage: DC 12V, 45mA
  • Speed: 3000 R.P.M. ± 10%
  • Airflow: 7.1 CFM(ft3/min)
  • Noise Level: 16.0 dB(A)



System Requirements:

  • Windows 2000, XP, Vista, 7, 8 (32 or 64bit)
  • Mac OS 10.4 or later
  • USB 3.0:
    Windows XP or later
    Mac OS 10.5 or later



LCD Module:

  • Displays RAID information
  • Displays system temperature



In the Box:

  • 1x CalDigit VR2
  • 1x Driver & Manual (Download)
  • 1x USB 3.0 Cable
  • 1x FireWire 800 Cable
  • 1x AC Adapter
  • 1x AC Power Cord
  • 2x Keys

TS2

macOS Drivers:



Windows Drivers:

Interface

2 x Thunderbolt™ 2 Ports
1 x HDMI 1.4b
1 x Gigabit Ethernet RJ-45
3 x USB 3.0 (1x Front, 2x Rear)
2 x eSATA 6G Ports
1 x Stereo Headphone 3.5mm
1 x Mono Microphone 3.5mm

Dimensions

Height: 1.71 inches (43.5 mm)
Width: 3.88 inches (98.5 mm)
Depth: 1.34 lbs (0.61 kgs)
Weight: 4.92 inches (125 mm)

Power Supply Adapter
Full range AC Input:
100V-240V ~ 50/60Hz 1.5A max
DC Output: DC 12V/5.0A
EMC: CE, UL, GS, CCC, FCC, CS, BSMI, PCT, ETL, PSE

Compliance

FCC, CE, RoHS

System Requirements

Thunderbolt™ enabled computer
Windows 7, 8 & Windows 10
Mac OS X 10.8.4 or later

Ambient Operating Temperature:
32°F ~ 158°F (0°C ~ 70°C)​

In the Box
1 x CalDigit Thunderbolt™ Station 2
1 x Power Supply
1 x Power Cord
2 x Rubber Feet Strips​

TS1

macOS Drivers:

Windows Drivers:

Interface

2 x Thunderbolt
3 x USB 3.0 (1x Front)
1 x Gigabit Ethernet
1 x HDMI Out
1 x Headphone Out
1 x Microphone In



Dimensions

6.85" (L) x 3.15" (W) x 1.02" (H)
17.4cm(L) x 8cm(W) x 2.6cm(H)
Weight 0.4 kg / 0.88 lbs.



System Requirements

Thunderbolt enabled computer
Mac OS X 10.8.4 or later
Windows 7 & Windows 8



Power Supply

AC Power Adapter Full range
Output: DC 12V, 5A Max
EMC: CE, UL, GS, CCC



Environment

Operating Humidity-0% RH~80% RH
Operating Temperature-0˚C~70˚C



Compliance

FCC , CE, RoHS



In the Box

1 x CalDigit Thunderbolt Station
1 x Power Supply​

VR 2

Capacity: up to 10TB



Size and Weight:
Height: 3.6 inches   (92 mm)
Width: 5.3 inches   (134 mm)
Depth: 8.5 inches   (216 mm)
Weight: 6.6lbs          (3.0 kgs)



Host Interface:
eSATA x 1
FireWire 800 x 2
FireWire 400 x 1
USB 3.0 x 1



Interface Transfer Rate:
eSATA: up to 3Gbits/s
FireWire 800: up to 800Mbits/s
FireWire 400: up to 400Mbits/s
USB 3.0: up to 5Gbits/s



RAID Function:
Supports RAID 0, 1, Spanning, JBOD
Automatically online fast disk rebuilding
Automatic disk failure detection
Hot swappable disks
USB 3.0 do not support JBOD



Power Supply Adapter:
Full range AC Input: 100 ~ 240V 50~60Hz 1.5A
DC Output: 5V/4.2A, 12V/3A
Power plug: 4Pin



Fan Module:
Size: 50(L) x 50(W) x 10(H) mm
Rated Voltage: DC 12V, 45mA
Speed: 3000 R.P.M. ± 10%
Airflow: 7.1 CFM(ft3/min)
Noise Level: 16.0 dB(A)



System Requirements:
Windows 2000, XP, Vista, 7, 8 (32 or 64bit)
Mac OS 10.4 or later



USB 3.0:
Windows XP or later
Mac OS 10.5 or later



LCD Module:
Displays RAID information
Displays system temperature



In the Box:
1x CalDigit VR2
1x Driver & Manual (Download)
1x USB 3.0 Cable
1x FireWire 800 Cable
1x AC Adapter
1x AC Power Cord
2x Keys

VR MINI 2

Interface and Data Transfer
1x SuperSpeed USB3.0 Port up to 5Gbps
2x FireWire 800 (IEEE 1394b) Ports up to 800Mbps



Size and Weight
Height: 2.07 inches (5.25 cm)
Width: 3.25 inches (8.25 cm)
Depth: 5.49 inches (13.95 cm)
Weight: 1.54lbs (0.7 kgs)



RAID Function
Supports RAID 0, 1, Spanning, JBOD
Automatically online fast disk rebuilding
Automatic disk failure detection/warning Hot swappable disks
USB3.0 interface only supports RAID 0, 1 and Spanning



Capacity
2TB



HDD
5400RPM

Power Supply Adapter
Full range AC Input: 100V-240V ~ 50/60Hz 0.6A
DC Output: 12V/1.5A
Power plug: 3.5x1.35x10(mm) S Type



S1394 Bus Power
1394 Bus Power 30V/1.5A(max)



LCD Module
Displays RAID information and system temperature
Configurable LCD panel with full access on RAID/MISC configurations



System Requirements
Windows 7, Vista, XP
Mac OS 10.5 or later

In the Box​
1x CalDigit VR mini 2
2x Driver modules
1x USB 3.0 cable
1x AC Power Adapter
1x AC Power Adapter Chip-on Plug​
