9 Ports
4x Thunderbolt 5 | USB4 v2
3x USB-A 10Gb/s
2x USB-C 10Gb/s
3 Displays
90W Charging
Get to Know the Element 5 Hub
Your Thunderbolt™ 5 Connectivity. Sorted.
The Most Compact Thunderbolt 5 Hub
The CalDigit Element 5 Hub (E5) is a truly unique device. It features more ports than any other Thunderbolt hub. It does this while also maintaining the exact same compact size as the previous Thunderbolt 4 Element Hub. With a wide selection of powerful ports, it is an ideal solution for expanding workflows, while taking up minimal desk space.
Even though the device is compact, it includes features found in high-end docks, such as 90W of consistent host charging, up to 120Gb/s connectivity, and support for up to 3 displays on supported Windows Thunderbolt 5 PCs.
Connect what you need, when you need.
Not Your Average Hub
Traditional USB hubs are mostly equipped with low performing ports, or ports with insufficient power delivery in order to keep your devices charged.
The Element 5 Hub allows you to have both great performance, and consistent power, thanks to the up to 120Gb/s throughput of Thunderbolt 5.
Total Compatibility
When you have such a powerful hub you also need the flexibility to use it with any device.
The Element 5 Hub is compatible with Thunderbolt 5, Thunderbolt 4, Thunderbolt 3 Macs, USB4, USB4 v2, and USB-C devices.
This also includes USB-C or Thunderbolt iPads, iPhones, Windows tablets and more*.
*The Element 5 Hub does not support Thunderbolt 3 Windows PCs. Users on Thunderbolt 3, Thunderbolt 4, and USB-C host computers, tablets, or phones will see reduced functionality.
Thunderbolt 5
The benefit of a Thunderbolt 5 hub is that you can connect many types of devices to it.
The Element 5 Hub features 3 downstream Thunderbolt 5 ports that can connect to monitors, fast external storage, and more.
The 15W performance of the downstream Thunderbolt 5 ports means you can charge and power devices much faster than USB hubs.
Define Your Connectivity
The simplicity of the Element 5 Hub’s four Thunderbolt 5 ports allows you to create the hub that you want. Don’t be confined by pre-built hubs. Use the Thunderbolt 5 ports to connect what you want.
Need to connect multiple SSDs, SD card readers, RAID storage, triple 4K monitors? No problem.
The Element 5 Hub is a blank canvas ready to be populated with the devices you need.
Faster than Your Average Hub
The Thunderbolt 5 ports on the Element 5 Hub provide up to 6,200MB/s performance for your external storage devices, which is double that of Thunderbolt 4, and much higher than typical USB hubs.
| Element 5 Hub (Thunderbolt 5) | USB-C 5Gb/s Hub (USB-A) | |
|---|---|---|
|
Max. External Storage Performance |
Up to 6,200MB/s* |
350MB/s (Typical performance) |
|
Performance Difference |
17x Faster |
17x Slower |
*Thunderbolt SSDs are only compatible with Thunderbolt & USB4 host computers. The actual performance may be slightly slower due to latency and protocol overhead.
Versatile USB Ports
The versatility of having both USB-C and USB-A ports offers great convenience. All of the USB ports on the Element 5 Hub offer 10Gb/s performance, and 7.5W of power.
This is an ideal option for connecting high performance USB-C SSDs to the hub. Don’t forget that you can also connect USB-C devices to the Thunderbolt 5 ports.
3 Monitors on Windows
Thunderbolt 5 allows for 3 external monitors to be connected to a Windows host computer that supports it, and the fact that the Element 5 Hub has 3 downstream Thunderbolt 5 ports makes it ideal for users that intend on connecting 3 displays*.
*Triple displays requires a compatible Thunderbolt 5 Windows PC. M4 Apple Macs do not support triple displays via a single Thunderbolt 5 host connection. Thunderbolt 4 Windows or Mac host computers do not support triple displays.
Bandwidth Boost
When you connect bandwidth intensive monitors to the Element 5 Hub it will enable Bandwidth Boost in order to priorotize displays, and provide up to 120Gb/s performance. This will then keep 40Gb/s for the rest of the dock.
The great thing about this is that it will allow for higher refresh rate displays to be connected to the device, as well as three 4K 60Hz displays on Windows Thunderbolt 5 PCs.
Single, Dual, or Triple Displays
Whether you need a high-resolution display, a high-refresh rate display, or up to 3 external displays, the Element 5 Hub has you covered.
Single Monitor
If you’re looking to add a single monitor to the Element 5 Hub you can connect it to one of the spare Thunderbolt 5 ports. If you wish to connect an HDMI monitor you can use a USB-C to HDMI Adapter ***.
Dual Monitors
- macOS users on base M4, M1/M2/M3/M4 Pro, M1/M2/M3/M4 Max, M1/M2 Ultra, or Intel based Macs can connect up to dual displays.
- M1/M2/M3 based Macs are limited to 1 external monitor by design via their Thunderbolt ports.
- Windows PC Thunderbolt 5 and Thunderbolt 4 users can connect up to dual displays.
Triple Monitors
- macOS does not support Triple monitors via a Thunderbolt Dock or Hub.
- Windows PC Thunderbolt 5 users can connect up to three displays on supported host computers.
- Windows PC Thunderbolt 4 users cannot connect three displays natively.
Reversible Design
A great function of the Element 5 Hub’s design is that it is reversible allowing you to be able to use it on either side of your laptop. This allows users to have more flexibility and freedom when designing their specific set-up.
iPads, iPhones & Windows Tablets
Not only is the Element 5 Hub compatible with laptops, it can be used with Thunderbolt or USB-C tablets and phones. This includes iPads and iPhones.
You are no longer limited to connecting a single device to your table or phone’s Type-C port. The Element 5 Hub will add up to 8 devices for next-level connectivity.
*Functionality will be reduced when using the Element 5 Hub on phones or tablets.
90W - Enough Power to Fast Charge your Apple Devices
Traditional USB hubs cannot compete with the Element 5 Hub’s power delivery. This is thanks to the included power supply which provides a “sustained” 90W of power delivery at all times to the host device.
USB hubs that claim up to 100W power delivery often reduce the actual power delivery based on how many USB devices are connected to it. Rest assured that this does not happen with the Element 5 Hub because of the included 180W power supply.
90W - Enough Power to Fast Charge All of Your Apple Devices
| Apple Device | Fast Charging |
|---|---|
|
13" MacBook Air (M1) |
48W |
|
13" MacBook Pro (M2) |
60W |
|
15" MacBook Air (M2) |
70W |
|
13" MacBook Air (M3) |
72W |
|
14" MacBook Pro (M4) |
90W |
|
iPad Pro (M4) |
45W |
|
iPhone 16 Pro Max |
45W |
|
Vision Pro Battery |
65W |
Docking Station Utility
Adding multiple devices to your hub is great but it can be a nuisance having to manually eject every storage device safely.
To solve this problem we have created a macOS Utility Software that allows users to quickly and safely eject all of their storage devices with one click.
Your Ultimate Charging Hub
- Apple Watch
- AirPods
- iPhone 16
- iPhone 16 Pro
- Magic Mouse (USB-C)
- MagSafe Charger
- iPad Pro
- AirPods Max
- MacBook Pro
A Powerful Offline Charging Station
The Element 5 Hub can even work for you when it’s not connected to your computer. Keep your USB-A or USB-C devices connected to the Element 5 Hub and it will continue to charge them. All 9 ports on the Element 5 Hub can be used at the same time for offline charging.
42% Smaller Power Supply
The Element 5 Hub’s power supply is 42% smaller than the previous generation, and also 30W more powerful.
This makes it even more convenient when travelling with the Element 5 Hub.
Apple SuperDrive
Many docks and hubs are not compatible with the Apple SuperDrive since it requires extra power from the connected USB port. In fact Apple recommends to connect it directly to a computer. CalDigit has solved this problem by creating a driver that will allow the SuperDrive to work through the Element 5 Hub.
Premium Features
Interface
- 1 x Thunderbolt 5 Host (Up to 120Gb/s)
- 3 x Thunderbolt 5 (80Gb/s)
- 3 x USB-A (10Gb/s)
- 2 x USB-C (10Gb/s)
- 1 x DC In (20V | 9A)
Minimum System Requirements
- macOS 15 or above
- Windows 11 or above
- iPadOS
- Chrome OS
- Thunderbolt 5 Computer
- Thunderbolt 4 Computer
- Thunderbolt 3 Mac
- USB-C (USB4 or USB4 v2) Computer
- USB-C Computer/Tablet/Phone
- Thunderbolt/USB4 iPad
- USB-C ChromeBook
Power Delivery
- Up to 90W Host Charging
- Each Downstream Thunderbolt 5 / USB4 v2 Port: 15W (5V/3A)
- Each USB-A Port: 7.5W (5V/1.5A)
- Each USB-C Port: 7.5W (5V/1.5A)
Size & Weight
- Height: 1.0″ (25.5mm)
- Width: 2.75″ (70 mm)
- Length: 4.48″ (114mm)
- Weight: 0.44lbs (0.20kg)
In The Box
- 1 x Element 5 Hub
- 1 x Thunderbolt 5 Cable (0.8m)
- 2 x Rubber Feet Strips
- 1 x Power Supply (180W)
- 1 x Power Cord
Warranty
- 2 Years
| Element 5 Hub (Thunderbolt 5) | Element Hub (Thunderbolt 4) | |
|---|---|---|
|
Max. Performance |
120Gb/s |
40Gb/s |
|
No. Ports |
9 |
8 |
|
Host Charging |
90W |
60W |
|
Max. PCI Express Bandwidth |
64Gb/s |
32Gb/s |
|
Three 4K 60Hz Displays (On Supported Thunderbolt 5 Windows PCs) |
✓ |
X |
|
Dual 4K 240Hz Displays |
✓ |
X |
|
Dual 6K 60Hz Displays |
✓ |
✓ |
|
10Gb/s USB-A |
3x |
4x |
|
10Gb/s USB-C |
2x |
0x |
|
Supports USB 20Gb/s Data Path (On Supported Thunderbolt 5 Windows PCs) |
✓ |
X |
|
DisplayPort Version |
2.1 |
1.4 |
|
Power Supply |
180W (Compact Design) |
150W (Larger Design) |
|
Price |
|
|
Apple M4 Macs with Thunderbolt 5 ports do not natively support 3 external displays via a dock or hub over one Thunderbolt 5 connection. The maximum number of displays they support is 2.
This is the case with any Thunderbolt 5 dock or hub.
For more information about how many monitors can be connected to a Mac, please visit https://support.apple.com/en-us/101571 and https://www.caldigit.com/macbook-multiple-monitor-support-with-caldigit-thunderbolt-docks/
Yes, the Element 5 Hub works on Thunderbolt 4 Macs, Thunderbolt 4 PCs, and Thunderbolt 3 Intel Macs. It however does not support Thunderbolt 3 Windows PCs.
Thunderbolt 4 and Thunderbolt 3 are both 40Gb/s, and the Element 5 Hub works great on both. However, to get the maximum performance and features out of the Element 5 Hub it should be used with a Thunderbolt 5 or USB4 v2 computer.
For Thunderbolt 4 and Thunderbolt 5 Windows PCs, please check with your manufacturer to see how many displays your PC supports from a single Thunderbolt connection, including if charging has been restricted via the Thunderbolt ports.
On macOS, to take advantage of the full Thunderbolt 5 bandwidth and features of the Element 5 Hub, an M4 Pro or Max Mac is required. Users on Apple Silicon Thunderbolt 4 Macs (M1-M3 and M4 base) will see reduced functionality. The maximum number of displays that can be connected on macOS via a single Thunderbolt connection is 2, even on an M4 Max, as long as your particular Mac supports 2 displays.
Yes, the Element 5 Hub is the perfect companion for the above Apple Silicon Macs.
Base M1-M3 Macs only support a single display through the Thunderbolt connection.
Pro, Max, M4 base, and Ultra Mac users can connect dual displays to the Element 5 Hub.
Three displays are not supported through a dock or hub on M4 Thunderbolt 5 Macs via a single Thunderbolt 5 connection.
Yes, the Element 5 Hub is a great option for Mac mini and iMac users to expand their connectivity.
When connected to the Mac mini or iMac, the Element 5 Hub will not supply any power to the computer.
Yes, the Element 5 Hub can be daisy-chained to the TS4, or any dual port Thunderbolt 3, or Thunderbolt 4 device such as the TS4. You can either have it first or second in the chain. We would recommend to have the TS4 directly connected to the laptop since it provides higher laptop charging.
If you plan to use your own laptop charger, we suggest you connect the Element 5 Hub to your computer first then daisy-chain it to other devices from the Element 5 Hub.
Unlike the majority of hubs or docks on the market that feature Dynamic Charging which decrease the charging performance when USB devices are connected to the hub, the Element 5 Hub features Full Consistent charging and will always provide 90W of power to the host computer.
Since the Element 5 Hub is a compact hub rather than a larger dock, heat management is of paramount importance.
90W is the optimum power delivery for hub of this size in order to provide enough power and keep the device at the perfect temperature.
If your laptop is above 90W the Element Hub will still charge your laptop at a slower speed.
If you are using CPU or GPU intensive applications we recommend that you connect the laptop’s charger to your laptop.
If you require a device with faster laptop charging, CalDigit offers full size docks with 98W charging.
No, the Element 5 Hub requires a power supply in order to operate.
The host Thunderbolt 5 connection provides 90W of power, the remaining Thunderbolt ports each provide up to 15W of power, and the USB ports provide up to 7.5W of power. To provide this much power the Element 5 Hub requires a power supply. However, the power supply that is included is very compact, making it ideal for travelling with.
Yes, the Element 5 Hub can charge your laptop at the same time as charging USB devices.
If your monitor is Thunderbolt or USB-C it can connect directly to the spare Thunderbolt 5 ports on the Element 5 Hub.
If you want to connect an HDMI or DisplayPort monitor you can purchase a USB-C to HDMI, or USB-C to DisplayPort Adapter, and connect it to the spare Thunderbolt ports.
You can connect any Thunderbolt 3, Thunderbolt 4, Thunderbolt 5, USB4, USB4 v2, or USB-C devices to the Thunderbolt ports on the Element 5 Hub.
This includes, but is not limited to, external storage, eGPUs, docks, monitors, 10G Ethernet adapter, USB-C to SD card readers, and USB-C to ethernet adapters.
You can also daisy chain multiple Element 5 Hubs together.
